3 Roller Hydraulic Symmetrical Plate Rolling Machine For Shipbuilding / Petroleum

جزئیات محصول

Place of Origin: China

نام تجاری: Friendship Machinery

گواهی: CE, ISO

Model Number: W11Y

شرایط پرداخت و حمل و نقل

Minimum Order Quantity: 1

Packaging Details: Standard export packing

Delivery Time: 30 working days

Supply Ability: 10 sets per month

بهترین قیمت را دریافت کنید
برجسته کردن:

hydraulic press brake machine,cnc hydraulic shearing machine

,

cnc hydraulic shearing machine

Model:
W11Y 6*6000
Control type:
NC
Driven method:
Hydraulic
Model:
W11Y 6*6000
Control type:
NC
Driven method:
Hydraulic
3 Roller Hydraulic Symmetrical Plate Rolling Machine For Shipbuilding / Petroleum

1. Main Summarize



    W11Y-6×6000 3 roller hydraulic symmetrical plate rolling machine, suit to bend mild steel thickness not more than 6mm when it’s width is 6000mm under the normal temperature condition; if use it to bend mild steel width less than 6000mm, it can to bend thicker mild steel, but the accurate bend thickness should to calculate; and if use it to bend other kinds steel sheet with different yielding limit, the max thickness should to do calculation.



    W11Y-series device widely used in manufacturing industries for example boiler, shipbuilding, petroleum, chemical, cement and motor and so on.

W11Y-series device with compacted structure, easy to operate, and widely selected by users in actual production.





2. Technical parameters



Model Unit W11Y-6×6000
Yielding limit of bended sheet Mpa σs≤245
Maximum bended thickness mm 6
Maximum bended width mm 6000
Diameter of up roller mm Φ330
Diameter of bottom rollers mm Φ200
Distance between two bottom rollers mm 320
Minimum diameter when full load mm Φ650
Rolling speed m/min About 4
Lifting speed of up roller mm/min About 120
Support roller / 3 sets * 4
Main motor power KW 11
Hydraulic motor power KW

5.5

Total weight kg 17000
Overall dimension mm 8500×1500×2000





3 Roller Hydraulic Symmetrical Plate Rolling Machine For Shipbuilding / Petroleum 0



3 Roller Hydraulic Symmetrical Plate Rolling Machine For Shipbuilding / Petroleum 1
