Mechanical Steel Plate Bending Machine , Hydraulic Steel Sheet Rolling Machine

جزئیات محصول

Place of Origin: China

نام تجاری: Friendship Machinery

گواهی: CE, ISO

Model Number: FSM-PB

شرایط پرداخت و حمل و نقل

Minimum Order Quantity: 1

Packaging Details: wooden pallet

Delivery Time: 20 working days

Supply Ability: 30 sets per month

بهترین قیمت را دریافت کنید
برجسته کردن:

hydraulic guillotine shearing machine,cnc hydraulic shearing machine

,

cnc hydraulic shearing machine

Maximum thickness of plate:
16mm
Maximum width of plate:
3000mm
Yielding limit sheet metal:
245º
Loaded with minimum coil diameter:
Φ800mm
Bending roll speed:
4m/min
Two bottomroller center distance:
430mm
Maximum thickness of plate:
16mm
Maximum width of plate:
3000mm
Yielding limit sheet metal:
245º
Loaded with minimum coil diameter:
Φ800mm
Bending roll speed:
4m/min
Two bottomroller center distance:
430mm
Mechanical Steel Plate Bending Machine , Hydraulic Steel Sheet Rolling Machine



1. Technical parameter



No. Item Unit Value
1 Maximum thickness of plate mm 16
2 Maximum width of plate mm 3000
3 Yielding limit sheet metal º 245
4 Loaded with minimum coil diameter mm Φ800
5 Bending roll speed m/min 4
6 Two bottomroller center distance mm 430
7 Upper roller diameter mm 340
8 Bottom roller diameter mm 260
9 Motor power KW 18.5







2. Description of structure



    The machine adopts 3-roller symmetrical structure with the upper roller moving vertically in the center between the two lower rollers, which is achieved through the drive of the screw, the nut, the worm and the lead screw, the two lower rollers, and provides the plate materials with torque through the engagement of the output gear of the moderator with the fear of the lower rollers. The machine is the overall structure, the working section and the main transmission section are all installed on a rigid welding base. It is convenient to installation and adjustment.
