CE ماشین فشار هیدرولیک فشار ماشین CNC ورق خم ماشین 6100 * 2500 * 4200MM
مدل | WC67Y-600T / 6000 | کنترل کننده | E21 |
---|---|---|---|
مقاومت ورق فولادی خم شده | 450N / mm2 | تقسیمات کلی | 6100 × 2500 × 4200 |
وزن کل | 52000 کیلوگرم | فشار کار سیستم هیدرولیک | 26 مگا |
برجسته | ,,sheet metal bending machine |
1. Overview
● The device adopts all steel-welded construction, and vibratory stress relief. Thus the device with good rigidity and high strength, to permit high accuracy.
● The whole frame with good rigidity, work is stable, safety and reliable, easy to operate.
● To adopt stress theory to control the deformation of structural parts effectively, so can to get satisfied work-piece.
● The workbench adopts bottom cylinder to do deflection compensation, to higher work accuracy.
● Controller: E21 from ESTUN is a cnc controller specialized in torsion axis synchronous press brake machine.
2. Technical parameters
Model | Units | WC67Y-600T/6000 | |
Controller | / | E21 | |
The bended steel sheet strength | N/mm2 | 450 | |
Nominal pressure | kN | 6000 | |
Worktable length | mm | 6000 | |
The distance between uprights | mm | 4850 | |
Throat depth | mm | 400 | |
Ram stroke | mm | 300 | |
Max opening height between worktable and ram | mm | 590 | |
Gear pump | Model | / | CP2-100-P-10R |
Flow | L/min | 100 | |
Pressure | Mpa | 31.5 | |
Ram speed | Unloaded | mm/s | 50 |
Work | mm/s | 6 | |
Return | mm/s | 60 | |
Working Pressure of hydraulic system | Mpa | 26 | |
Main motor Power | kW | 45 | |
Electrical system | V/Hz | 3 phase,380V, 50HZ | |
Total weight | kgs | 52000 | |
Overall diemension | mm | 6100×2500×4200 |
